AB93616

Anti-Nav1.8/SCN10A 抗体 [S134]

Name: Anti-Nav1.8/SCN10A 抗体 [S134] (ab93616) | Abcam
Brand: Abcam Limited
SKU: AB93616
Price: 26000 JPY
Availability: InStock
Rating: 4 (2 reviews)

Anti-Nav1.8/SCN10A antibody [S134]

BOND RX™ Validated
Recombinant
詳細を見る

(2 Reviews)

(10 Publications)

Anti-Nav1.8/SCN10A antibody [S134] (ab93616) is a mouse monoclonal antibody detecting Nav1.8/SCN10A in IHC-P. Suitable for Mouse, Rat.

- Trusted since 2010

別名を表示する

Sns, Scn10a, Sodium channel protein type 10 subunit alpha, Peripheral nerve sodium channel 3, Sensory neuron sodium channel, Sodium channel protein type X subunit alpha, Voltage-gated sodium channel subunit alpha Nav1.8, PN3

4 Images

Immunohistochemistry (Frozen sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized Rat dorsal root ganglion (fresh frozen) tissue labeling Nav1.8/SCN10A with ab93616 at 1/500 dilution followed by ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 (2 µg/mL) dilution (Green).

Confocal image showing positive staining on rat dorsal root ganglion tissue. The nuclear counterstain was DAPI (Blue). The section was incubated with ab93616 for 60mins at room temperature. The section was then mounted using Fluoromount^®. The immunostaining was performed on a Leica Biosystems BOND^® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Secondary antibody control : Secondary antibody is ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 (2 µg/mL) dilution.

IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized Rat skeletal muscle (fresh frozen) tissue labeling Nav1.8/SCN10A with ab93616 at 1/500 dilution followed by ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 (2 µg/mL) dilution (Green).

Negative control : confocal image showing no staining on rat skeletal muscle tissue (PMID : 24086692). The nuclear counterstain was DAPI (Blue). The section was incubated with ab93616 for 60mins at room temperature. The section was then mounted using Fluoromount^®.The immunostaining was performed on a Leica Biosystems BOND^® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Secondary antibody control : Secondary antibody is ab150117 Goat Anti-Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 (2 µg/mL) dilution.

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

Immunohistochemical analysis of paraffin-embedded Rat dorsal root ganglia labeling Nav1.8/SCN10A with ab93616 at 1/100 dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection). The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Counterstained with Hematoxylin. Heat mediated antigen retrieval was performed with EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Nav1.8/SCN10A antibody [S134] (AB93616)

Immunohistochemical analysis of paraffin-embedded Mouse dorsal root ganglia labeling Nav1.8/SCN10A with ab93616 at 1/100 dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection). The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Counterstained with Hematoxylin. Heat mediated antigen retrieval was performed with EDTA buffer (pH 9.0, epitope retrieval solution 2) for 20 mins.

Key facts

宿主種

Mouse

クローン性

Monoclonal

クローン番号

S134

アイソタイプ

IgG2a

キャリアフリー

交差種

Mouse, Rat

アプリケーション

IHC-Fr, IHC-P

applications

免疫原

Recombinant Fragment Protein within Rat Scn10a aa 1700 to C-terminus. The exact immunogen used to generate this antibody is proprietary information.

Q62968

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "IHCFr" : {"fullname" : "Immunohistochemistry (Frozen sections)", "shortname":"IHC-Fr"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Mouse": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "", "IHCFr-species-checked": "guaranteed", "IHCFr-species-dilution-info": "", "IHCFr-species-notes": "" }, "Rat": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "", "IHCFr-species-checked": "testedAndGuaranteed", "IHCFr-species-dilution-info": "1/500", "IHCFr-species-notes": "" } } }

style

left-column

製品の詳細

What is this antibody validated in?
Anti-Nav1.8/SCN10A antibody [S134] (ab93616) is a mouse recombinant monoclonal antibody and is validated for use in Immunohistochemistry (IHC-P) in Mouse, Rat samples.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

- High batch-to-batch consistency and reproducibility
- Improved sensitivity and specificity
- Long-term security of supply
- Animal-free batch production

For more information, read more on recombinant antibodies.

style

left-column

出荷温度及び保存条件

製品の状態

Liquid

精製方法

Affinity purification Protein A

バッファー組成

pH: 7.2 - 7.4 Preservative: 0.01% Sodium azide Constituents: PBS, 40% Glycerol (glycerin, glycerine), 0.05% BSA

出荷温度

Blue Ice

短期保存期間

1-2 weeks

短期保存温度

+4°C

長期保存温度

-20°C

分注に関する情報

Upon delivery aliquot

保管に関する情報

Avoid freeze / thaw cycle

style

left-column

補足情報

This supplementary information is collated from multiple sources and compiled automatically.

Nav1.8 also known as SCN10A is a voltage-gated sodium channel. It facilitates the rapid transit of sodium ions across cell membranes essential for the propagation of action potentials in neurons. Nav1.8 has a mass of approximately 220 kDa and it expresses primarily in peripheral sensory neurons including dorsal root ganglia. This channel is activated mainly in response to depolarization enabling the initiation and conduction of electrical signals.

Biological function summary

Nav1.8 contributes significantly to pain transmission especially in nociceptive neurons which detect painful stimuli. It operates as a principal component in generating sustained action potentials required for pain signal propagation. Nav1.8 is not a part of a larger complex but plays a standalone critical role. It shows high expression during inflammatory and neuropathic pain conditions indicating its role in pain pathways.

Pathways

Nav1.8 is involved in both the pain and neuroinflammatory pathways. It influences the activity of other sodium channels such as Nav1.7 another critical mediator of pain sensation. Pain pathways extensively integrate Nav1.8 function especially in the modulation of pain thresholds and states. Neuroinflammatory pathways utilize Nav1.8 to alter neuron excitability under inflammatory conditions which is significant for understanding different pain modalities.

Nav1.8 is associated with chronic pain disorders such as neuropathic pain and inflammatory pain conditions. Variations in Nav1.8 are linked to altered pain sensitivity and are researched as potential therapeutic targets for pain relief. In diseases like diabetic neuropathy Nav1.8 changes correlate with increased neuronal excitability and persistent pain sensation. Its relationship with proteins like Nav1.7 in these contexts highlights its importance in the diagnostic and therapeutic options for pain management.

style

left-column

style

left-column

製品プロトコール

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

ターゲットの情報

Tetrodotoxin-resistant channel that mediates the voltage-dependent sodium ion permeability of excitable membranes. Assuming opened or closed conformations in response to the voltage difference across the membrane, the protein forms a sodium-selective channel through which sodium ions may pass in accordance with their electrochemical gradient. Plays a role in neuropathic pain mechanisms.

See full target information Scn10a

style

left-column

文献 (10)

Recent publications for all applications. Explore the full list and refine your search

BMC cardiovascular disorders 24:605 PubMed39472780

2024

Blocking Na1.8 regulates atrial fibrillation inducibility and cardiac conduction after myocardial infarction.

Applications

Unspecified application

Species

Unspecified reactive species

Baozhen Qi,Zhonglei Xie,Dongli Shen,Yu Song,Shaowen Liu,Qibing Wang,Jingmin Zhou,Junbo Ge

eLife 12: PubMed38289829

2024

Spatial transcriptomics and single-nucleus RNA sequencing reveal a transcriptomic atlas of adult human spinal cord.

Applications

Unspecified application

Species

Unspecified reactive species

Donghang Zhang,Yali Chen,Yiyong Wei,Hongjun Chen,Yujie Wu,Lin Wu,Jin Li,Qiyang Ren,Changhong Miao,Tao Zhu,Jin Liu,Bowen Ke,Cheng Zhou

Epileptic disorders : international epilepsy journal with videotape 24:647-656 PubMed35872622

2022

Cu-Zn SOD suppresses epilepsy in pilocarpine-treated rats and alters SCN2A/Nrf2/HO-1 expression

Applications

Unspecified application

Species

Unspecified reactive species

Fang Wen,Zhi-Gang Tan,Jun Xiang

Allergy 76:3422-3432 PubMed33884632

2021

Central, but not peripheral, nervous system ERK2 is essential for itch signals in murine allergic skin inflammation.

Applications

Unspecified application

Species

Unspecified reactive species

Shinsuke Matsuo,Takashi Hashimoto,Fumhiro Matsuura,Osamu Imamura,Shogo Endo,Yasushi Satoh,Takahiro Satoh

Bioengineering (Basel, Switzerland) 7: PubMed32429423

2020

Conserved Expression of Nav1.7 and Nav1.8 Contribute to the Spontaneous and Thermally Evoked Excitability in IL-6 and NGF-Sensitized Adult Dorsal Root Ganglion Neurons In Vitro.

Applications

Unspecified application

Species

Unspecified reactive species

Rahul R Atmaramani,Bryan J Black,June Bryan de la Peña,Zachary T Campbell,Joseph J Pancrazio

Nature communications 10:5643 PubMed31822662

2019

Sensory innervation in porous endplates by Netrin-1 from osteoclasts mediates PGE2-induced spinal hypersensitivity in mice.

Applications

Unspecified application

Species

Unspecified reactive species

Shuangfei Ni,Zemin Ling,Xiao Wang,Yong Cao,Tianding Wu,Ruoxian Deng,Janet L Crane,Richard Skolasky,Shadpour Demehri,Gehua Zhen,Amit Jain,Panfeng Wu,Dayu Pan,Bo Hu,Xiao Lyu,Yusheng Li,Hao Chen,Huabin Qi,Yun Guan,Xinzhong Dong,Mei Wan,Xuenong Zou,Hongbin Lu,Jianzhong Hu,Xu Cao

Neuron 102:801-812.e5 PubMed30926280

2019

Location and Plasticity of the Sodium Spike Initiation Zone in Nociceptive Terminals In Vivo.

Applications

Unspecified application

Species

Unspecified reactive species

Robert H Goldstein,Omer Barkai,Almudena Íñigo-Portugués,Ben Katz,Shaya Lev,Alexander M Binshtok

PloS one 8:e76084 PubMed24086692

2013

The voltage-gated sodium channel nav1.8 is expressed in human sperm.

Applications

ICC/IF, Flow Cyt

Species

Human, Human

Antonio Cejudo-Roman,Francisco M Pinto,Nerea Subirán,Cristina G Ravina,Manuel Fernández-Sánchez,Natalia Pérez-Hernández,Ricardo Pérez,Alberto Pacheco,Jon Irazusta,Luz Candenas

Journal of neurophysiology 110:1535-43 PubMed23843437

2013

Identification of CaV channel types expressed in muscle afferent neurons.

Applications

Unspecified application

Species

Unspecified reactive species

Renuka Ramachandra,Bassil Hassan,Stephanie G McGrew,James Dompor,Mohamed Farrag,Victor Ruiz-Velasco,Keith S Elmslie

Journal of neurophysiology 108:2230-41 PubMed22855776

2012

Tetrodotoxin-resistant voltage-dependent sodium channels in identified muscle afferent neurons.

Applications

IHC

Species

Unspecified reactive species

Renuka Ramachandra,Stephanie Y McGrew,James C Baxter,Esad Kiveric,Keith S Elmslie

View all publications

style

left-column

style

left-column

style

right-column

Abcam product promise

当社は、高品質な試薬を通じてお客様の研究を力強くサポートすることをお約束いたします。ご使用いただく各段階で、常にお客様をサポートできる体制を整えております。万が一、製品が期待通りに機能しない場合は、「Abcam Product Promise」による当社保証制度に基づき、安心してご利用いただけます。

保証に関する詳細については利用規約をご確認ください。

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.

For licensing inquiries, please contact partnerships@abcam.com
