AB201825

Alexa Fluor® 647 Anti-PD1 抗体 [EPR4877(2)]

Name: Alexa Fluor® 647 Anti-PD1 抗体 [EPR4877(2)] (ab201825) | Abcam
Brand: Abcam Limited
SKU: AB201825
Price: 89000 JPY
Availability: InStock
Rating: 5 (1 reviews)

Alexa Fluor® 647 Anti-PD1 antibody [EPR4877(2)]

RabMAb
Recombinant
詳細を見る

(1 Review)

(13 Publications)

Anti-PD1 antibody [EPR4877(2)] - Alexa Fluor® 647 conjugated (ab201825) is a rabbit recombinant monoclonal antibody detecting PD1 in IHC-P. Suitable for Human.

- Biophysical QC for unrivalled batch-batch consistency

別名を表示する

CD279, PD1, PDCD1, Programmed cell death protein 1, Protein PD-1, hPD-1

2 Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-PD1 antibody [EPR4877(2)] (AB201825)

IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-PD1 antibody [EPR4877(2)] (AB201825)

IHC image of PD1 staining in a section of formalin-fixed paraffin-embedded normal human tonsil*.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Dako Pascal pressure cooker using the standard factory-set regime. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature. The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab201825 at 1/100 dilution (shown in red) and counterstained using ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 488), at 1/250 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.

IHC-P

AbReview82002****

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-PD1 antibody [EPR4877(2)] (AB201825)

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of 10% NBF-fixed human tonsil tissue staining with ab201825 at 1/100 dilution. Samples were incubated with the primary antibody with Intercept for 18 hours. Intercept 100% for 30 minutes at room temperature. Heat mediated antigen retrieval with Tris/EDTA pH 9.0.

This image is courtesy of an anonymous Abreview

Key facts

宿主種

Rabbit

クローン性

Monoclonal

クローン番号

EPR4877(2)

アイソタイプ

IgG

標識

Alexa Fluor® 647

励起波長/蛍光波長

Ex: 650nm, Em: 665nm

キャリアフリー

交差種

Human

アプリケーション

IHC-P

applications

免疫原

The exact immunogen used to generate this antibody is proprietary information.

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "<p></p>" } } }

style

left-column

製品の詳細

What is this antibody validated in?
Alexa Fluor® 647 Anti-PD1 antibody [EPR4877(2)] (ab201825) is a rabbit recombinant monoclonal antibody and is validated for use in Immunohistochemistry (IHC-P) in Human samples.

Related products
Antibody clone EPR4877(2) is also available pre-conjugated to a variety of labels for your convenience – Anti-PD1 Alexa Fluor® 647 [EPR4877(2)] (ab201825).

Other related products
We have a range of other formats of antibody clone [EPR4877(2)] also available for your convenience: ab137132, Carrier free - ab186928, Alexa Fluor® 647 - ab201825, Alexa Fluor® 555 - ab275126, Alexa Fluor® 594 - ab275349, Alexa Fluor® 488 - ab311022, Alexa Fluor® 568 - ab313074, Alexa Fluor® 750 - ab321110

Patented technology
Our RabMAb^® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb^® patents.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style

left-column

出荷温度及び保存条件

製品の状態

Liquid

精製方法

Affinity purification Protein A

バッファー組成

pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

出荷温度

Blue Ice

短期保存期間

1-2 weeks

短期保存温度

+4°C

長期保存温度

-20°C

分注に関する情報

Upon delivery aliquot

保管に関する情報

Avoid freeze / thaw cycle|Store in the dark

style

left-column

補足情報

This supplementary information is collated from multiple sources and compiled automatically.

PD1 also known as Programmed Cell Death Protein 1 or PDCD1 is a transmembrane protein that plays a critical role in regulating immune responses. It has a mass of approximately 55 kDa. PD1 is expressed on the surface of T cells B cells and some myeloid cells. PD1’s expression increases upon activation of these immune cells assisting in maintaining peripheral tolerance. Researchers often use PD1 mouse models and chimeric antibodies to explore the function of PD1 for experimental purposes. Antibodies such as anti-PD1 such as EH12.2H7 help in blocking PD1 interaction to study its role further.

Biological function summary

PD1 serves as an inhibitory receptor acting as a checkpoint in the immune system. It becomes part of an immune-suppressive complex when it binds with its ligands PD-L1 or PD-L2 which are expressed on various cell types including some tumor cells. This interaction suppresses the proliferation of T cells and cytokine production contributing to immune homeostasis. By controlling T cell activity PD1 limits autoimmunity but can also reduce the immune system's capability to attack cancer cells.

Pathways

PD1 functions in the immune checkpoint pathway a critical regulatory circuit in immune regulation. The engagement of PD1 with its ligands initiates a cascade that inhibits the function and proliferation of T cells through downstream SHP-2 phosphatase activity. This pathway frequently involves other regulatory proteins like CTLA-4 and is an important mechanism by which the body modulates immune responses. Related pathways often intersect with those involving T cell receptor signaling and contribute to the overall modulation of immune activity.

PD1 has a significant role in cancer and autoimmune disorders. PD1 expression can allow tumors to evade immune surveillance making PD1 a target for cancer therapies such as anti-PD1 antibodies which aim to block PD1 and restore T cell activity. The interaction of PD1 with cancer-related proteins like PD-L1 facilitates tumor immune evasion. In autoimmune disorders PD1’s regulation of immune balance can become dysregulated leading to persistent immune activation and tissue damage. Understanding PD1 and its interaction with proteins such as PD-L1 helps in developing therapeutic strategies for both cancer and autoimmune conditions.

style

left-column

style

left-column

製品プロトコール

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

ターゲットの情報

The protein expressed by the gene PDCD1 functions as an inhibitory receptor on antigen-activated T-cells, playing a critical role in the induction and maintenance of immune tolerance to self. It delivers inhibitory signals by binding to the ligands CD274/PDCD1L1 and CD273/PDCD1LG2. Tumors exploit the PDCD1-mediated inhibitory pathway to attenuate anti-tumor immunity, enabling tumor survival by evading immune system destruction. The interaction with CD274/PDCD1L1 inhibits the effector function of cytotoxic T lymphocytes (CTLs). Blocking the PDCD1-mediated pathway can reverse the exhausted T-cell phenotype and normalize the anti-tumor response, providing a rationale for cancer immunotherapy. This supplementary information is collated from multiple sources and compiled automatically.

See full target information PDCD1

style

left-column

文献 (13)

Recent publications for all applications. Explore the full list and refine your search

STAR protocols 6:103946 PubMed40652508

2025

Protocol for studying the immune microenvironment of human hepatocellular carcinoma by Cell DIVE multiplex immunofluorescence imaging.

Applications

Unspecified application

Species

Unspecified reactive species

Margaux Delaporte,Maelle Guillout,Pascale Bellaud,Anthony Sébillot,Bruno Turlin,Thierry Pécot,Michel Samson,Céline Raguénès-Nicol

Nature methods 21:2248-2259 PubMed39478175

2024

Quality control for single-cell analysis of high-plex tissue profiles using CyLinter.

Applications

Unspecified application

Species

Unspecified reactive species

Gregory J Baker,Edward Novikov,Ziyuan Zhao,Tuulia Vallius,Janae A Davis,Jia-Ren Lin,Jeremy L Muhlich,Elizabeth A Mittendorf,Sandro Santagata,Jennifer L Guerriero,Peter K Sorger

iScience 27:110668 PubMed39246442

2024

Multiplex imaging of localized prostate tumors reveals altered spatial organization of AR-positive cells in the microenvironment.

Applications

Unspecified application

Species

Unspecified reactive species

Çiğdem Ak,Zeynep Sayar,Guillaume Thibault,Erik A Burlingame,M J Kuykendall,Jennifer Eng,Alex Chitsazan,Koei Chin,Andrew C Adey,Christopher Boniface,Paul T Spellman,George V Thomas,Ryan P Kopp,Emek Demir,Young Hwan Chang,Vasilis Stavrinides,Sebnem Ece Eksi

Nature communications 14:7479 PubMed37980418

2023

Comprehensive analysis reveals potential therapeutic targets and an integrated risk stratification model for solitary fibrous tumors.

Applications

Unspecified application

Species

Unspecified reactive species

Renjing Zhang,Yang Yang,Chunfang Hu,Mayan Huang,Wenjian Cen,Dongyi Ling,Yakang Long,Xin-Hua Yang,Boheng Xu,Junling Peng,Sujie Wang,Weijie Zhu,Mingbiao Wei,Jiaojiao Yang,Yuxia Xu,Xu Zhang,Jiangjun Ma,Fang Wang,Hongtu Zhang,Peiqing Ma,Xiaojun Zhu,Guohui Song,Li-Yue Sun,De-Shen Wang,Feng-Hua Wang,Yu-Hong Li,Sandro Santagata,Qin Li,Yan-Fen Feng,Ziming Du

Cancer cell 41:871-886.e10 PubMed37059105

2023

Lymphocyte networks are dynamic cellular communities in the immunoregulatory landscape of lung adenocarcinoma.

Applications

Unspecified application

Species

Unspecified reactive species

Giorgio Gaglia,Megan L Burger,Cecily C Ritch,Danae Rammos,Yang Dai,Grace E Crossland,Sara Z Tavana,Simon Warchol,Alex M Jaeger,Santiago Naranjo,Shannon Coy,Ajit J Nirmal,Robert Krueger,Jia-Ren Lin,Hanspeter Pfister,Peter K Sorger,Tyler Jacks,Sandro Santagata

Cell genomics 2: PubMed36419822

2022

Spatial intra-tumor heterogeneity is associated with survival of lung adenocarcinoma patients.

Applications

Unspecified application

Species

Unspecified reactive species

Hua-Jun Wu,Daniel Temko,Zoltan Maliga,Andre L Moreira,Emi Sei,Darlan Conterno Minussi,Jamie Dean,Charlotte Lee,Qiong Xu,Guillaume Hochart,Connor A Jacobson,Clarence Yapp,Denis Schapiro,Peter K Sorger,Erin H Seeley,Nicholas Navin,Robert J Downey,Franziska Michor

Nature protocols 17:3028-3055 PubMed36180532

2022

Multispectral confocal 3D imaging of intact healthy and tumor tissue using mLSR-3D.

Applications

Unspecified application

Species

Unspecified reactive species

Ravian L van Ineveld,Raphaël Collot,Mario Barrera Román,Anna Pagliaro,Nils Bessler,Hendrikus C R Ariese,Michiel Kleinnijenhuis,Marcel Kool,Maria Alieva,Susana M Chuva de Sousa Lopes,Ellen J Wehrens,Anne C Rios

Nature immunology 23:1256-1272 PubMed35902638

2022

Partial RAG deficiency in humans induces dysregulated peripheral lymphocyte development and humoral tolerance defect with accumulation of T-bet B cells.

Applications

Unspecified application

Species

Unspecified reactive species

Krisztian Csomos,Boglarka Ujhazi,Peter Blazso,Jose L Herrera,Christopher M Tipton,Tomoki Kawai,Sumai Gordon,Maryssa Ellison,Kevin Wu,Matthew Stowell,Lauren Haynes,Rachel Cruz,Bence Zakota,Johnny Nguyen,Michelle Altrich,Christoph B Geier,Svetlana Sharapova,Joseph F Dasso,Jennifer W Leiding,Grace Smith,Waleed Al-Herz,Mayra de Barros Dorna,Olajumoke Fadugba,Eva Fronkova,Veronika Kanderova,Michael Svaton,Sarah E Henrickson,Joseph D Hernandez,Taco Kuijpers,Snezhina Mihailova Kandilarova,Elizaveta Naumova,Tomas Milota,Anna Sediva,Despina Moshous,Benedicte Neven,Tara Saco,Ravishankar Sargur,Sinisa Savic,John Sleasman,Gauri Sunkersett,Brant R Ward,Masanobu Komatsu,Stefania Pittaluga,Attila Kumanovics,Manish J Butte,Michael P Cancro,Shiv Pillai,Eric Meffre,Luigi D Notarangelo,Jolan E Walter

Nature cancer 2:66-82 PubMed33738458

2021

Targeting immunosuppressive macrophages overcomes PARP inhibitor resistance in BRCA1-associated triple-negative breast cancer.

Applications

Unspecified application

Species

Unspecified reactive species

Anita K Mehta,Emily M Cheney,Christina A Hartl,Constantia Pantelidou,Madisson Oliwa,Jessica A Castrillon,Jia-Ren Lin,Katie E Hurst,Mateus de Oliveira Taveira,Nathan T Johnson,William M Oldham,Marian Kalocsay,Matthew J Berberich,Sarah A Boswell,Aditi Kothari,Shawn Johnson,Deborah A Dillon,Mikel Lipschitz,Scott Rodig,Sandro Santagata,Judy E Garber,Nadine Tung,José Yélamos,Jessica E Thaxton,Elizabeth A Mittendorf,Peter K Sorger,Geoffrey I Shapiro,Jennifer L Guerriero

Cancer cell 37:720-734.e13 PubMed32359397

2020

Comprehensive Molecular Characterization Identifies Distinct Genomic and Immune Hallmarks of Renal Medullary Carcinoma.

Applications

Unspecified application

Species

Unspecified reactive species

Pavlos Msaouel,Gabriel G Malouf,Xiaoping Su,Hui Yao,Durga N Tripathi,Melinda Soeung,Jianjun Gao,Priya Rao,Cristian Coarfa,Chad J Creighton,Jean-Philippe Bertocchio,Selvi Kunnimalaiyaan,Asha S Multani,Jorge Blando,Rong He,Daniel D Shapiro,Luigi Perelli,Sanjana Srinivasan,Federica Carbone,Patrick G Pilié,Menuka Karki,Riyad N H Seervai,Bujamin H Vokshi,Dolores Lopez-Terrada,Emily H Cheng,Ximing Tang,Wei Lu,Ignacio I Wistuba,Timothy C Thompson,Irwin Davidson,Virginia Giuliani,Katharina Schlacher,Alessandro Carugo,Timothy P Heffernan,Padmanee Sharma,Jose A Karam,Christopher G Wood,Cheryl L Walker,Giannicola Genovese,Nizar M Tannir

View all publications

style

left-column

style

left-column

style

right-column

Abcam product promise

当社は、高品質な試薬を通じてお客様の研究を力強くサポートすることをお約束いたします。ご使用いただく各段階で、常にお客様をサポートできる体制を整えております。万が一、製品が期待通りに機能しない場合は、「Abcam Product Promise」による当社保証制度に基づき、安心してご利用いただけます。

保証に関する詳細については利用規約をご確認ください。

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
